Vortex acoustic insulated flexible duct R1.0, 300mm x 6m (VH300)

Vortex acoustic insulated flexible duct R1.0, 300mm x 6m (VH300)

The VH300 is a 300mm Vortex Acoustic flexible duct, insulated to R1.0 and supplied 6m long for ducted heating and cooling.

• Brand: Vortex
• Insulation: R1.0
• Diameter: 300mm
• Length: 6m
• Metalised inner core wrapped in polyester insulation, with a metalised outer fire jacket
• Operating temperature: -20°C to +80°C
• Operating pressure: -190Pa to +1200Pa
• Complies with AS 4254.1
• Code: VH300
• Range: Vortex Acoustic

A 300mm duct suits runs between fittings with 300mm spigots, which in many layouts sit between the unit or plenum and the smaller branch runs. Pull the duct straight, secure the core over the spigot with a strap and tape, then seal the insulation and outer jacket. Plan the route so bends are wide and the duct is supported along its length.

Check the insulation R-value required for your climate zone and application before ordering. Confirm with the system design that acoustic duct and a 300mm size are specified for this run, and that there is space for it in the ceiling.
