Insulated ceiling box 300mm square, 250mm spigot (CHB3030-25)

Insulated ceiling box 300mm square, 250mm spigot (CHB3030-25)

AAD CHB3030-25 is an internally insulated ceiling box, 300mm square and 320mm deep, with a 250mm spigot and a damper blade. It links flexible duct to a ceiling diffuser.

• Brand: AAD
• Face: 300mm square
• Depth: 320mm
• Spigot: 250mm
• Internally insulated, with damper blade
• 40mm lip
• Code: CHB3030-25
• Insulation: 20mm internal
• Ceiling type: metal T bar
• Listed to suit: ALD445 diffuser

This is the 300mm square box with the larger 250mm spigot, and it is listed at 320mm deep. The diffuser fits below and the duct connects to the spigot, taped and strapped. The damper blade is set during commissioning to balance the air to that outlet. The catalogue lists it to suit the ALD445 diffuser.

Confirm the face size suits your diffuser, the duct is 250mm and there is at least 320mm of clearance above the ceiling for the box depth.
