Airloc Smartfit insulated Y fitting 400/250/250mm (AY161010)

Airloc Smartfit insulated Y fitting 400/250/250mm (AY161010)

This Airloc Smartfit insulated Y fitting, code AY161010, splits a 400mm duct into two 250mm branches, stepping down in size as it divides.

• Brand: AAD
• Inlet: 400mm
• Outlets: 250mm and 250mm
• Material: plastic
• Insulated
• Code: AY161010
• Range: Airloc Smartfit
• Shape: Y, two equal outlets

A 400mm inlet means the fitting usually sits on a main trunk, close to where the air leaves the indoor unit or a large plenum. The two 250mm legs then head off to separate parts of the system. Tape and strap all three connections, and fix the fitting securely, as a 400mm duct is heavy and can drag a fitting out of position. Spigot sizes can be changed with Airloc Smartfit adaptors (sold separately).

Check the duct sizes in your system design before ordering. Check that your design shows a 400mm feed dividing into two 250mm branches at this point. Measure the ceiling space, as this is a large fitting.
